Dtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery
  • Air ProDtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery
  • Air ProDtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery
  • Air ProDtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery
  • Air ProDtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery

Dtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery

Dongguan Encore Energy Rechargeable Small Cylinder 3.7v Lipo 40mah battery have characteristic design & practical performance & competitive price, for more information on the Rechargeable Small Cylinder 3.7v Lipo Battery, please feel free to contact us.

Model:50310

Send Inquiry

Product Description

Adhering to your principle of "quality, assistance, performance and growth", we have now gained trusts and praises from domestic and international customer for 351120 Lipo Battery 3.7V 40mAh Rechargeable Lithium Battery, Hope we can create a more glorious future with you through our efforts in the future. 351120 Lipo Battery 3.7V 40mAh Rechargeable Lithium Battery Power Supply, Lithium Battery, Power Bank, As an experienced manufacturer we also accept customized order and we could make it the same as your picture or sample specification. The main goal of our company is to live a satisfactory memory to all the customers, and establish a long term business relationship with buyers and users all over the world.We can constantly satisfy our respected customers with our good high quality, good price tag and good support due to we have been additional specialist and extra hard-working and do it in cost-effective way for Li Polymer Batteries Lp351120 40mAh 3.7V 40mAh Lipo Battery 351120 401118 Small Lipo Battery 40mAh for Bluetooth Earphone Very Thin Lithium Polymer, First company, we understand each other. Further more company, the trust is getting there. Our enterprise normally at your provider anytime. Li Polymer Batteries Lp351120 40mAh 3.7V 40mAh Lipo Battery 351120 401118 Small Lipo Battery 40mAh for Bluetooth Earphone Very Thin Lithium Polymer 351120 Lipo Battery, Lipo Battery 3.7V, Li-Polymer Battery, Welcome to visit our company, factory and our showroom where displays various hair solutions that will meet your expectation. Meanwhile, it is convenient to visit our website, and our sales staff will try their best to deliver you the best service. Be sure to contact us if you want more information. Our aim is to help customers realize their goals. We are making great efforts to achieve this win-win situation.Reliable top quality and great credit score standing are our principles, which will help us at a top-ranking position. Adhering on the tenet of "quality first, consumer supreme" for 3.7V 40mAh Lithium Polymer Battery for Mini Fan, Sincerely stay up for serving you from the in the vicinity of future. You are sincerely welcome to go to our company to talk company face to face with each other and create long-term co-operation with us! 3.7V 40mAh Lithium Polymer Battery for Mini Fan 3.7V 40mAh Lithium Battery, 40mAh Battery, 3.7V 40mAh Lipo Battery, With good quality, reasonable price and sincere service, we enjoy a good reputation. Items are exported to South America, Australia, Southeast Asia and so on. Warmly welcome customers at home and abroad to cooperate with us for the brilliant future.Our solutions are greatly recognized and reliable by customers and will fulfill continuously altering financial and social requirements for 401015 40mAh 3.7V Lithium Polymer Battery, Our enterprise warmly welcome close friends from everywhere in the environment to go to, examine and negotiate organization. 401015 40mAh 3.7V Lithium, Polymer, Battery, We strongly believe that technology and service is our base today and quality will create our reliable walls of future. Only we've got better and better quality , could we achieve our customers and ourselves, too. Welcome customers all over the word to contact us for getting further business and reliable relationships. We've been always here working for your demands whenever you need to have.Our enterprise since its inception, constantly regards product good quality as organization life, constantly improve production technology, strengthen merchandise high quality and continuously strengthen enterprise total good quality administration, in strict accordance with all the national standard ISO 9001:2000 for Lithium Button Cell Cr1220 3V 40mAh Dry Battery, "Quality first, Price lowest, Service best" is the spirit of our company. We sincerely welcome you to visit our company and negotiate mutual business! Lithium Button Cell Cr1220 3V 40mAh Dry Battery Lithium Button Cell Battery, Dry Battery, Button Cell Battery, Our mission is "Provide Products and solutions with Reliable Quality and Reasonable Prices". We welcome customers from every corner of the world to contact us for future business relationships and achieving mutual success!The buyer pleasure is our primary concentrate on. We uphold a consistent level of professionalism, excellent, credibility and service for Smallest Li-ion Battery 351120 3.7V 40mAh Lithium Polymer Battery Mini Rechargeable Battery, We are ready to cooperate with organization pals from at your home and abroad and make a great long term together. Smallest Li-ion Battery 351120 3.7V 40mAh Lithium Polymer Battery Mini Rechargeable Battery Mini Lithium Battery, Small Lithium Polymer Battery, Small Lipo Battery, Our tenet is "integrity first, quality best". We now have confidence in providing you with excellent service and ideal goods. We sincerely hope we can establish win-win business cooperation with you in the future!We hold strengthening and perfecting our items and repair. At the same time, we get the job done actively to do research and progress for Dtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery, We welcome new and aged buyers from all walks of lifetime to make contact with us for potential small business associations and mutual success! Dtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery, 3.7V Battery, Small Li Polymer Battery, At Current, our solutions have been exported to more than sixty countries and different regions, such as Southeast Asia, America, Africa, Eastern Europe, Russia, Canada etc. We sincerely hope to establish wide contact with all potential customers both in China and the rest part of the world.
Dongguan Encore Energy Rechargeable Small Cylinder 503100 3.7v 40mah Lipo Battery have characteristic design & practical performance & competitive price, for more information on the Rechargeable Small Cylinder 3.7v Lipo Dtp 301120 3.7V 40mAh Lipo Battery with Jst Phr 2.0 Connector Bluetooth Earphone Battery , please feel free to contact us.

■ Features

● Rechargeable Lithium-ion Polymer(LiPO)

● Nominal capacity: 40mAh

● Nominal voltage: 3.7V

● Standard Charge: 6.5 hours

● Charge Temp.10-45℃

● Discharge Temp.-10℃ to 60℃

● Over Charge/Discharge Protection

● Short Circuit Protection

● Dimensions: 5.0x31.0mm

● 1-year Warranty

● Cycle Life: Over 300 times

■ Applications

● Widely used in communications, factories, finance, lighting energy, digital products, 3C consumer electronics and other fields.

■ Model List

Model Number Nominal Capacity Nominal Voltage Standard Charge Time Charge Limited Voltage
EN70300 100mAh 3.7V 6.5 hours 4.2V

■ Technical Data

Rated Capacity 100mAh
Minimum Capacity 100mAh
Nominal Voltage 3.7V
Charge Limited Voltage 4.2V
Discharge Cut-off Voltage 3.0V
End-of-charge Current 0.02C
Standard Charge Charge with 0.2C(20mA) up to limited Voltage, Charge with limited Voltage up to end-of-charge current.
Standard Discharge Using 0.2C(20mA) constant current discharge to the Discharge cut-off Voltage.
Maximum Continuous Charge Current 1C(100mA)
Maximum Continuous Discharge Current 1C(100mA)
Maximum Pulse Discahrge Current 1C
Operating Temperature Range Charge 0~45℃
Discharge -10~60℃
Storage Temperature Range -10~45℃ less than 1month
-10~35℃ less than 6month
Operating And Storage Humidity Range 75% RH or less
Weight Approx 2.1g
Open Circuit Voltage 3.75V-3.95V
Internal Impedance Single Cell: ≤380Ω

■ Mechanical Diagram

■ PCM Parameter

Item Condition Specification
input Voltage input Voltage B+ to B- /
Overcharge Detection voltage /
Release voltage /
Detection delay time /
Over discharge Detection voltage /
Release voltage /
Detection delay time /
Over discharge current Over current /
Delay time /
Shortage Protection Short detection delay time /
Release Conditions /
Normal current consumption Normal current consumption of PCM /
Suggest working conditions Max continuous charge/discharge current /
Suggest working temperature /
IR resistance IR of PCM /
NTC/ resistance / /
The size of final PCM The diameter of final PCM /
The thickness of final PCM /

■ About Company

Dongguan Encore Energy Co.,Ltd established in the year of 2016, Encore Energy is a professional engaged in the research, development, production, sales and service of Polymer lithium-ion battery,Disposable lithium battery,Cylindrical lithium battery,Square lithium battery.Encore Energy located in Dongguan City, Guangdong Province,China with convenient transportation access.The factory size of 10,000 square meters, We have introduction of domestic advanced automation equipment, including automatic winding machine, automatic pack machine. Automatic printer and so on.

We also welcome Customized size and shaped design battery orders. Whether selecting a current battery from our current sizes or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements.

■ Certification

■ UL1642 Certified battery size:

No Cylinder/Capacity Size ( D*L)mm Certification Remarks
1 302020-80mAh 3.0*20.0*20.8 UL1642
2 302530-180mAh 3.0*25.0*30.0 UL1642
3 351213-35mAh 3.6*12.0*13.5 UL1642
4 353035-350mAh 3.5*30.0*35.0 UL1642
5 372135-250mAh 3.7*21.0*35.0 UL1642
6 381424-80mAh 3.8*14.0*22.0 UL1642 5C Fast Charge
7 401020-50mAh 4.0*10.0*20.0 UL1642
8 401030-90mAh 4.0*10.0*30.0 UL1642
9 401220-70mAh 4.0*12.5*20.0 UL1642
10 401230-125mAh 4.0*12.0*30.0 UL1642
11 402030-200mAh 4.0*20.0*29.5 UL1642 Normal and 15C High Rate
12 410929-80mAh 4.1*9.0*29.0 UL1642
13 421217-50mAh 4.2*12.0*17.0 UL1642
14 432126-190mAh 4.3*21.0*26.0 UL1642
15 451220-70mAh 4.5*12.0*20.0 UL1642
16 455080-2100mAh 4.5*50.0*80.0 UL1642
17 462558-720mAh 4.6*25.0*58.0 UL1642
18 465782-3450mAh 4.6*57.0*82.0 UL1642 4.35V
19 500930-90mAh 5.0*9.0*28.0 UL1642 5C Fast Charge
20 501015-50mAh 5.0*10.0*15.0 UL1642
21 501225-110mAh 5.0*12.0*25.0 UL1642
22 501227-110mAh 5.0*12.0*25.0 UL1642 5C Fast Charge
23 501447-280mAh 5.2*14.0*47.5 UL1642 3A Discharge
24 502030-250mAh 5.0*20.0*30.0 UL1642
25 502530-300mAh 5.0*25.0*30.0 UL1642
26 502540-500mAh 5.0*25.0*38.5 UL1642
27 503035-500mAh 5.0*30.0*35.5 UL1642
28 503040-550mAh 5.0*30.0*40.0 UL1642
29 504040-480mAh 5.0*40.0*38.0 UL1642
30 504050-1000mAh 5.0*40.0*50.0 UL1642
31 5267105-5000mAh 5.2*67.0*105.0 UL1642
32 551245-220mAh 5.5*12.0*45.0 UL1642
33 552530-410mAh 5.5*25.0*30.5 UL1642
34 553825-500mAh 5.5*38.0*25.0 UL1642
35 554270-1900mAh 5.5*42.0*70.0 UL1642
36 581038-180mAh 5.8*10.0*38.0 UL1642
37 582235-380mAh 6.0*22.5*37.5 UL1642
38 582751-825mAh 5.8*27.0*51.0 UL1642
39 601818-140mAh 6.0*18.0*18.0 UL1642
40 602025-250mAh 6.0*20.0*25.5 UL1642
41 602030-300mAh 6.0*20.0*30.5 UL1642
42 602040-450mAh 6.0*20.0*39.5 UL1642
43 602240-500mAh 6.0*22.0*40.5 UL1642
44 603048-850mAh 6.0*30.0*48.0 UL1642
45 603759-1400mAh 6.0*37.0*59.0 UL1642
46 651448-450mAh 6.5*14.0*48.0 UL1642
47 653030-500mAh 6.5*30.0*28.0 UL1642
48 653040-800mAh 6.5*30.0*40.5 UL1642
49 701250-380mAh 7.0*12.0*50.0 UL1642
50 701340-300mAh 7.0*13.0*40.0 UL1642
51 703351-1100mAh 7.0*33.0*51.0 UL1642
52 705070-3000mAh 7.0*50.0*70.0 UL1642
53 733960-1800mAh 7.3*39.0*60.0 UL1642
54 782551-1000mAh 7.8*25.0*51.0 UL1642
55 783048-1150mAh 7.8*30.0*48.0 UL1642
56 801437-370mAh 8.1*14.0*37.5 UL1642 3A Discharge
57 801534-350mAh 8.1*15.5*34.5 UL1642 3A Discharge
58 802035-480mAh 8.0*20.0*33.0 UL1642
59 802040-600mAH 8.0*20.0*40.0 UL1642
60 802230-400mAh 8.0*22.0*30.0 UL1642
61 802530-500mAh 8.0*25.0*30.0 UL1642
62 803860-2000mAh 8.0*38.0*60.0 UL1642
63 822129-400mAh 8.2*21.0*29.0 UL1642
64 833338-1280mAh 8.3*33.0*38.0 UL1642
65 102020-300mAh 10.0*20.0*20.5 UL1642
66 103450-1800mAh 10.0*34.0*50.0 UL1642
Cylindrical Battery
1 50300-45mAh 5.5*31.0 UL1642
2 65180-40mAh 6.5*18.5 UL1642 4C Discharge
3 60270-55mAh 6.0*27.0 UL1642
4 72530-200mAh 7.2*53.0 UL1642
5 75100-20mAh 7.5*10.0 UL1642
6 75300-100mAh 7.5*30.5 UL1642 3A Discharge
7 75350-130mAh 7.5*35.0 UL1642
8 08120-50mAh 8.3*12.5 UL1642
9 08160-60mAh 8.3*16.5 UL1642
10 08300-120mAh 8.5*30.0 UL1642
11 08400-180mAh 8.5*40.5 UL1642 1.2A Discharge
12 08500-260mAh 8.3*50.5 UL1642 1.5A Discharge
13 08570-280mAh 8.5*57.5 UL1642 3A Discharge
14 09130-65mAh 9.5*13.5 UL1642
15 09260-180mAh 9.5*26.5 UL1642
16 10100-60mAh 10.5*11.0 UL1642 Normal,3C Fast Charge
17 10150-80mAh 10.5*15.0 UL1642
18 10350-300mAh 10.0*35.0 UL1642
19 10380-300mAh 10.0*38.0 UL1642
20 10400-280mAh 9.8*41.0 UL1642 3A Discharge
21 10440-330mAh 10.0*44.0 UL1642
22 10540-50mAh 10.0*54.0 UL1642
23 1254-50mAh 12.0*54.0 UL1642
24 14540-85mAh 14.0*54.0 UL1642
25 13250-400mAh 13.0*25.0 UL1642
26 13300-500mAh 13.0*30.0 UL1642
27 13350-550mAh 13.0*35.0 UL1642
28 13400-550mAh 13.0*40.0 UL1642
29 13420-750mAh 13.0*42.0 UL1642
30 13450-650mAh 13.0*45.0 UL1642
31 14500-800mAh 14.0*50.0 UL1642
32 15380-680mAh 15.0*38.0 UL1642
33 16350-650mAh 16.0*35.0 UL1642
34 17350-850mAh 17.0*35.0 UL1642
35 18350-800mAh 18.0*35.0 UL1642

■ Packing and Shipment

1. Standard export carton packaging or Custom-made Package

2. Mode of Transport:

By express UPS/DHL/FEDEX/TNT (It takes 3-25 working days to arrive).

By air cargo (It takes about 1 week to arrive)

By sea shipment (It takes about 1 month to arrive)

3. Delivery 3-25 working days after payment and packing confirmation.

■ Warnings

1. Failure to observe the following precautions may result in battery leakage, explosion or fire.

- Do not immerse the battery in water or allow it to get wet.

- Do not use or store the battery near sources of heat such as a fire or heater.

- Do not reverse the positive (+) and negative (-) terminals.

- Do not connect the battery directly to wall outlets or car cigarette-lighter sockets.

- Do not put the battery into a fire or apply direct heat to it.

- Do not short-circuit the battery by connecting wires or other metal objects to the positive (+) and negative (-) terminals.

- Do not place the battery in a microwave oven or pressurized container.

- Do not use the battery in combination with primary batteries (such as alkaline batteries) or batteries of different capacity, type or brand.

- Do not use the battery if it gives off an odor, generates heat, becomes discolored or deformed, or appears abnormal in any way.

If the battery is in use or being recharged, remove it from the device or charger immediately and discontinue use.

- Do not pierce the battery casing with a nail or other sharp object, break it open with a hammer, or step on it.

- Do not attempt to disassemble the battery in any way.

- Keep the batteries out of the reach of children. If a child somehow swallows a battery, seek medical attention immediately.

- If the battery leaks and electrolyte gets in your eyes, do not rub them. rinse them with clean running water and immediately seek medical attention.

If left as is, electrolyte can cause eye injury.

- The isolated measures are needed between battery (the bare Al layer at side and top sealing) and the PCB, and also between battery and electric equipment,

especially avoid the Al layer in packing foil contact to cathode or anode (including electric equipment), otherwise this can cause battery leakage or swelling.

Hot Tags: Bluetooth Earphone Battery, 3.7V Battery, Small Li Polymer Battery
