Lithium Polymer Battery Lp603450 Lipo Battery Li-Po 603450 3.7V 1000mAh Lp 603450 for Electric Device

You can rest assured to buy customized 504050 3.7v 1000mah lipo JST connector lithium polymer battery for portable exchange device with UL from us. We look forward to cooperating with you, if you want to know more, you can consult us now, we will reply to you in time!

Model:504050

Send Inquiry

Product Description

We stick to our company spirit of "Quality, Effectiveness, Innovation and Integrity". We purpose to create far more value for our shoppers with our abundant resources, sophisticated machinery, experienced workers and exceptional expert services for Improve Rechargeable 3.7V 1000mAh Lithium Polymer Cell 504050 Lipo Battery with Jst Connector, Base within the small business concept of Top quality initially, we want to fulfill more and additional friends within the word and we hope provide the ideal solution and services to you. Improve Rechargeable 3.7V 1000mAh Lithium Polymer Cell 504050 Lipo Battery with Jst Connector Customized Battery, 1000mAh Lithium Battery, 3.7V Li Polymer Battery, Honest to every customers are our requested! First-class serve, best quality, best price and fastest delivery date is our advantage! Give every customers good serve is our tenet! This makes our company get the favour of customers and support! Welcome all over the world customers send us enquiry and looking forward your good co-operation !You should your inquiry for more details or request for dealership in selected regions.Our solutions are broadly acknowledged and dependable by users and may meet consistently developing economic and social requires for 3.7V 1000mAh 504050 Lithium Polymer Battery for Vacuum Cleaner, We welcome clients, business enterprise associations and mates from all pieces from the earth to make contact with us and request cooperation for mutual advantages. 3.7V 1000mAh 504050 Lithium Polymer Battery for Vacuum Cleaner Li-Polymer Battery, Li-ion Battery, Lithium Battery Pack, Our company now has many department, and there have more than 20 employees in our company. We set up sales shop, show room, and product warehouse. In the meantime, we registered our own brand. We have tightened inspection for quality of product.Our growth depends within the innovative equipment, fantastic talents and repeatedly strengthened technology forces for UL IEC62133 Kc Lithium Polymer Battery 3.7V 1050mAh 603450 Lipo Battery 1000mAh with PCM for LED Light, Our experienced specialized workforce will probably be wholeheartedly at your provider. We sincerely welcome you to check out our web-site and organization and mail us your inquiry. UL IEC62133 Kc Lithium Polymer Battery 3.7V 1050mAh 603450 Lipo Battery, 3.7V Lipo Battery, 3.7V Lithium Battery, At existing our sales network is growing continually, improving service quality to meet customer's demand. If you are interested in any goods , be sure to contact us at anytime. We have been looking forward to forming successful business relationships with you in near future.We insist on offering high-quality production with great enterprise concept, honest product sales and also the finest and fast service. it will bring you not only the superior quality solution and huge profit, but the most significant should be to occupy the endless market for China Supplier Lipo 523450 3.7V 1000mAh Lithium Polymer Battery with Kc UL List, With our rules of " small business track record, partner trust and mutual benefit", welcome all of you to definitely work together , expand with each other. China Supplier Lipo 523450 3.7V 1000mAh Lithium Polymer Battery with Kc UL List, China 523450, China Lithium Polymer Battery, We will supply much better products with diversified designs and professional services. At the same time, welcome OEM, ODM orders, invite friends at home and abroad together common development and achieve win-win, integrity innovation, and expand business opportunities! If you have any question or need more information please feel free to contact us. We are looking forward to receiving your enquiries soon.We now have a highly efficient crew to deal with inquiries from clients. Our intention is "100% shopper pleasure by our merchandise quality, price tag & our staff service" and take pleasure in a very good standing amongst purchasers. With quite a few factories, we can easily provide a wide vary of Lipo Battery 3.7V 1100mAh Lithium Polymer Battery 504050, The concept of our corporation is "Sincerity, Speed, Services, and Satisfaction". We're going to follow this concept and get more and additional customers' fulfillment. Lipo Battery 3.7V 1100mAh Lithium Polymer Battery, Lipo Battery, Lipo Battery Pack, "Create Values,Serving Customer!" is the aim we pursue. We sincerely hope that all customers will establish long term and mutually beneficial cooperation with us.If you wish to get more details about our company, Please contact with us now!"Control the standard by the details, show the power by quality". Our firm has strived to establish a extremely efficient and stable employees crew and explored an effective excellent command method for Factory OEM Rechargeable as 523450 3.7V 1000mAh Lithium Polymer Lipo Li-Polymer Battery with UL/Kc, We will do our best to meet your requirements and are sincerely looking forward to developing mutual beneficial business relationship with you! Factory OEM Rechargeable as 523450 3.7V 1000mAh Lithium Polymer Lipo Li-Polymer Battery with UL/Kc Lithium Battery, Lipo Battery, Li-Polymer Battery, We've got a good reputation for stable quality merchandise, well received by customers at home and abroad. Our company would be guided by the idea of "Standing in Domestic Markets, Walking into International Markets". We sincerely hope that we could do business with car manufacturers, auto part buyers and the majority of colleagues both at home and abroad. We expect sincere cooperation and common development!We support our consumers with ideal good quality merchandise and large level provider. Becoming the specialist manufacturer in this sector, we have attained wealthy practical encounter in producing and managing for 3.7V 200mAh 601235 Lipo Battery Rechargeable Lithium Polymer Ion Battery Pack with Jst Connector, We hope we can have a friendly relationship with businessman from all over the world. 3.7V 200mAh 601235 Lipo Battery Rechargeable Lithium Polymer Ion Battery Pack with Jst Connector 200mAh 3.7V Lithium Polymer Li-Po, Lipo Battery Cells 3.7V 200mAh, Venom Fly 3.7V 200mAh 30c 1s Lipo, With a wide range, good quality, reasonable prices and stylish designs, our merchandise are extensively used in public placesand other industries. Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs. We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!We are commitment to offer the competitive price ,outstanding products quality, as well as fast delivery for 3.7V 1500mAh 853450 Lipo Battery Rechargeable Lithium Polymer Battery Pack with Jst Connector, On account of superior top quality and aggressive selling price , we'll be the market leader, be sure to don’t wait to get in touch with us by phone or email, should you be intrigued in almost any of our products. 3.7V 1500mAh 853450 Lipo Battery Rechargeable Lithium Polymer Battery Pack with Jst Connector Li-Polymer 853450 Battery, Lithium Ion Battery - 1500mAh, Rechargeable Li-Poly Battery, With high quality, reasonable price, on-time delivery and customized & personalized services to help customers achieve their goals successfully, our company has got praise in both domestic and foreign markets. Buyers are welcome to contact us.Assume full accountability to satisfy all demands of our consumers; reach ongoing advancements by endorsing the expansion of our purchasers; come to be the final permanent cooperative partner of clients and maximize the interests of clientele for Lithium Polymer Battery Lp603450 Lipo Battery Li-Po 603450 3.7V 1000mAh Lp 603450 for Electric Device, Welcome to develop the perfectly and long standing enterprise relationships with our business to make a superb potential with each other. customers' satisfaction is our eternal pursuit! Lithium Polymer Battery Lp603450 Lipo Battery Li-Po 603450 3.7V 1000mAh Lp 603450 for Electric Device Lipo 1000mAh Battery, Lithium Polymer Battery, Rechargeable Lithium Batteries, We've more than 200 staff including experienced managers, creative designers, sophisticated engineers and skilled workers. Through hard work of all employees for the past 20 years own company grew stronger and stronger. We always apply the "client first" principle. We also always fulfill all contracts to the point and therefore enjoy excellent reputation and trust among our customers. You are very welcome to personally visit our company.We hope to start a business partnership on the basis of mutual benefit and successful development . For more information remember to do no hesitate to contact us.
You can rest assured to buy customized Lithium Polymer Battery Lp603450 Lipo Battery Li-Po 603450 3.7V 1000mAh Lp 603450 for Electric Device from us. We look forward to cooperating with you, if you want to know more, you can consult us now, we will reply to you in time!

■ Features

● Rechargeable Lithium-ion Polymer(LiPO)

● Nominal capacity: 1000mAh

● Nominal voltage: 3.7V

● Standard Charge: 6.5 hours

● Charge Temp.10-45℃

● Discharge Temp.-10℃ to 60℃

● Over Charge/Discharge Protection

● Short Circuit Protection

● Dimensions: 5.0x40.0x50.0mm

● 1-year Warranty

● Cycle Life: Over 300 times

■ Applications

● Widely used in communications, factories, finance, lighting energy, digital products, 3C consumer electronics and other fields.

■ Model List

Model Number Nominal Capacity Nominal Voltage Standard Charge Time Charge Limited Voltage
EN504050 1000mAh 3.7V 6.5 hours 4.2V

■ Technical Data

Rated Capacity 1000mAh
Minimum Capacity 1000mAh
Nominal Voltage 3.7V
Charge Limited Voltage 4.2V
Discharge Cut-off Voltage 3.0V
End-of-charge Current 0.02C
Standard Charge Charge with 0.2C(200mA) up to limited Voltage, Charge with limited Voltage up to end-of-charge current.
Standard Discharge Using 0.2C(200mA) constant current discharge to the Discharge cut-off Voltage.
Maximum Continuous Charge Current 1C(1000mA)
Maximum Continuous Discharge Current 1C(1000mA)
Maximum Pulse Discahrge Current 1C
Operating Temperature Range Charge 0~45℃
Discharge -10~60℃
Storage Temperature Range -10~45℃ less than 1month
-10~35℃ less than 6month
Operating And Storage Humidity Range 75% RH or less
Weight Approx 22.50g
Open Circuit Voltage 3.75V-3.95V
Internal Impedance Single Cell: ≤100Ω
Battery Pack: ≤180Ω

■ Mechanical Diagram

■ PCM Parameter

Item Condition Specification
input Voltage input Voltage B+ to B- -0.3~+12V
Overcharge Detection voltage 4.280±0.050V
Release voltage 4.080±0.100V
Detection delay time 0.96~1.40S
Over discharge Detection voltage 2.400±0.100V
Release voltage 3.000±0.100V
Detection delay time 115.0~173.0ms
Over discharge current Over current 2.0~5.0A
Delay time 7.20~11.0ms
Shortage Protection Short detection delay time 220~380us
Release Conditions Cut off load
Normal current consumption Normal current consumption of PCM Max 7.00 uA
0V charger allowed 0V charger Yes
IR resistance IR of PCM ≤65.00 mΩ
NTC/ resistance / /
The size of final PCM The length of final PCM 15.0±0.15mm
The width of final PCM 3.5±0.10mm
The thickness of final PCM Max2.40mm

■ About Company

Dongguan Encore Energy Co.,Ltd established in the year of 2016, Encore Energy is a professional engaged in the research, development, production, sales and service of Polymer lithium-ion battery,Disposable lithium battery,Cylindrical lithium battery,Square lithium battery.Encore Energy located in Dongguan City, Guangdong Province,China with convenient transportation access.The factory size of 10,000 square meters, We have introduction of domestic advanced automation equipment, including automatic winding machine, automatic pack machine. Automatic printer and so on.

We also welcome Customized size and shaped design battery orders. Whether selecting a current battery from our current sizes or seeking engineering assistance for your application, you can talk to our customer service center about your sourcing requirements.

■ Certification

■ UL1642 Certified battery size:

No Cylinder/Capacity Size ( D*L)mm Certification Remarks
1 302020-80mAh 3.0*20.0*20.8 UL1642
2 302530-180mAh 3.0*25.0*30.0 UL1642
3 351213-35mAh 3.6*12.0*13.5 UL1642
4 353035-350mAh 3.5*30.0*35.0 UL1642
5 372135-250mAh 3.7*21.0*35.0 UL1642
6 381424-80mAh 3.8*14.0*22.0 UL1642 5C Fast Charge
7 401020-50mAh 4.0*10.0*20.0 UL1642
8 401030-90mAh 4.0*10.0*30.0 UL1642
9 401220-70mAh 4.0*12.5*20.0 UL1642
10 401230-125mAh 4.0*12.0*30.0 UL1642
11 402030-200mAh 4.0*20.0*29.5 UL1642 Normal and 15C High Rate
12 410929-80mAh 4.1*9.0*29.0 UL1642
13 421217-50mAh 4.2*12.0*17.0 UL1642
14 432126-190mAh 4.3*21.0*26.0 UL1642
15 451220-70mAh 4.5*12.0*20.0 UL1642
16 455080-2100mAh 4.5*50.0*80.0 UL1642
17 462558-720mAh 4.6*25.0*58.0 UL1642
18 465782-3450mAh 4.6*57.0*82.0 UL1642 4.35V
19 500930-90mAh 5.0*9.0*28.0 UL1642 5C Fast Charge
20 501015-50mAh 5.0*10.0*15.0 UL1642
21 501225-110mAh 5.0*12.0*25.0 UL1642
22 501227-110mAh 5.0*12.0*25.0 UL1642 5C Fast Charge
23 501447-280mAh 5.2*14.0*47.5 UL1642 3A Discharge
24 502030-250mAh 5.0*20.0*30.0 UL1642
25 502530-300mAh 5.0*25.0*30.0 UL1642
26 502540-500mAh 5.0*25.0*38.5 UL1642
27 503035-500mAh 5.0*30.0*35.5 UL1642
28 503040-550mAh 5.0*30.0*40.0 UL1642
29 504040-480mAh 5.0*40.0*38.0 UL1642
30 504050-1000mAh 5.0*40.0*50.0 UL1642
31 5267105-5000mAh 5.2*67.0*105.0 UL1642
32 551245-220mAh 5.5*12.0*45.0 UL1642
33 552530-410mAh 5.5*25.0*30.5 UL1642
34 553825-500mAh 5.5*38.0*25.0 UL1642
35 554270-1900mAh 5.5*42.0*70.0 UL1642
36 581038-180mAh 5.8*10.0*38.0 UL1642
37 582235-380mAh 6.0*22.5*37.5 UL1642
38 582751-825mAh 5.8*27.0*51.0 UL1642
39 601818-140mAh 6.0*18.0*18.0 UL1642
40 602025-250mAh 6.0*20.0*25.5 UL1642
41 602030-300mAh 6.0*20.0*30.5 UL1642
42 602040-450mAh 6.0*20.0*39.5 UL1642
43 602240-500mAh 6.0*22.0*40.5 UL1642
44 603048-850mAh 6.0*30.0*48.0 UL1642
45 603759-1400mAh 6.0*37.0*59.0 UL1642
46 651448-450mAh 6.5*14.0*48.0 UL1642
47 653030-500mAh 6.5*30.0*28.0 UL1642
48 653040-800mAh 6.5*30.0*40.5 UL1642
49 701250-380mAh 7.0*12.0*50.0 UL1642
50 701340-300mAh 7.0*13.0*40.0 UL1642
51 703351-1100mAh 7.0*33.0*51.0 UL1642
52 705070-3000mAh 7.0*50.0*70.0 UL1642
53 733960-1800mAh 7.3*39.0*60.0 UL1642
54 782551-1000mAh 7.8*25.0*51.0 UL1642
55 783048-1150mAh 7.8*30.0*48.0 UL1642
56 801437-370mAh 8.1*14.0*37.5 UL1642 3A Discharge
57 801534-350mAh 8.1*15.5*34.5 UL1642 3A Discharge
58 802035-480mAh 8.0*20.0*33.0 UL1642
59 802040-600mAH 8.0*20.0*40.0 UL1642
60 802230-400mAh 8.0*22.0*30.0 UL1642
61 802530-500mAh 8.0*25.0*30.0 UL1642
62 803860-2000mAh 8.0*38.0*60.0 UL1642
63 822129-400mAh 8.2*21.0*29.0 UL1642
64 833338-1280mAh 8.3*33.0*38.0 UL1642
65 102020-300mAh 10.0*20.0*20.5 UL1642
66 103450-1800mAh 10.0*34.0*50.0 UL1642
Cylindrical Battery
1 50300-45mAh 5.5*31.0 UL1642
2 65180-40mAh 6.5*18.5 UL1642 4C Discharge
3 60270-55mAh 6.0*27.0 UL1642
4 72530-200mAh 7.2*53.0 UL1642
5 75100-20mAh 7.5*10.0 UL1642
6 75300-100mAh 7.5*30.5 UL1642 3A Discharge
7 75350-130mAh 7.5*35.0 UL1642
8 08120-50mAh 8.3*12.5 UL1642
9 08160-60mAh 8.3*16.5 UL1642
10 08300-120mAh 8.5*30.0 UL1642
11 08400-180mAh 8.5*40.5 UL1642 1.2A Discharge
12 08500-260mAh 8.3*50.5 UL1642 1.5A Discharge
13 08570-280mAh 8.5*57.5 UL1642 3A Discharge
14 09130-65mAh 9.5*13.5 UL1642
15 09260-180mAh 9.5*26.5 UL1642
16 10100-60mAh 10.5*11.0 UL1642 Normal,3C Fast Charge
17 10150-80mAh 10.5*15.0 UL1642
18 10350-300mAh 10.0*35.0 UL1642
19 10380-300mAh 10.0*38.0 UL1642
20 10400-280mAh 9.8*41.0 UL1642 3A Discharge
21 10440-330mAh 10.0*44.0 UL1642
22 10540-50mAh 10.0*54.0 UL1642
23 1254-50mAh 12.0*54.0 UL1642
24 14540-85mAh 14.0*54.0 UL1642
25 13250-400mAh 13.0*25.0 UL1642
26 13300-500mAh 13.0*30.0 UL1642
27 13350-550mAh 13.0*35.0 UL1642
28 13400-550mAh 13.0*40.0 UL1642
29 13420-750mAh 13.0*42.0 UL1642
30 13450-650mAh 13.0*45.0 UL1642
31 14500-800mAh 14.0*50.0 UL1642
32 15380-680mAh 15.0*38.0 UL1642
33 16350-650mAh 16.0*35.0 UL1642
34 17350-850mAh 17.0*35.0 UL1642
35 18350-800mAh 18.0*35.0 UL1642

■ Packing and Shipment

1. Standard export carton packaging or Custom-made Package

2. Mode of Transport:

By express UPS/DHL/FEDEX/TNT (It takes 3-25 working days to arrive).

By air cargo (It takes about 1 week to arrive)

By sea shipment (It takes about 1 month to arrive)

3. Delivery 3-25 working days after payment and packing confirmation.

■ Warnings

1. Failure to observe the following precautions may result in battery leakage, explosion or fire.

- Do not immerse the battery in water or allow it to get wet.

- Do not use or store the battery near sources of heat such as a fire or heater.

- Do not reverse the positive (+) and negative (-) terminals.

- Do not connect the battery directly to wall outlets or car cigarette-lighter sockets.

- Do not put the battery into a fire or apply direct heat to it.

- Do not short-circuit the battery by connecting wires or other metal objects to the positive (+) and negative (-) terminals.

- Do not place the battery in a microwave oven or pressurized container.

- Do not use the battery in combination with primary batteries (such as alkaline batteries) or batteries of different capacity, type or brand.

- Do not use the battery if it gives off an odor, generates heat, becomes discolored or deformed, or appears abnormal in any way.

If the battery is in use or being recharged, remove it from the device or charger immediately and discontinue use.

- Do not pierce the battery casing with a nail or other sharp object, break it open with a hammer, or step on it.

- Do not attempt to disassemble the battery in any way.

- Keep the batteries out of the reach of children. If a child somehow swallows a battery, seek medical attention immediately.

- If the battery leaks and electrolyte gets in your eyes, do not rub them. rinse them with clean running water and immediately seek medical attention.

If left as is, electrolyte can cause eye injury.

- The isolated measures are needed between battery (the bare Al layer at side and top sealing) and the PCB, and also between battery and electric equipment,

especially avoid the Al layer in packing foil contact to cathode or anode (including electric equipment), otherwise this can cause battery leakage or swelling.
